| Specifications | |
| Voltage | 12V |
| Kilowatt | 1.4kW |
| Number of Teeth | 13T |
| Pinion Diameter | 34mm |
| Rotation | CW |
| Pinion at Rest | -5mm |
| Flange Diameter | 63mm |
| Mount Hole Center to Center | 120 x 85 x 85mm |
| Mount Hole Diameter | M10 |
| Overall Length | 207mm |
| Oil Sealed | |
| Series | |
| Ground | NEGATIVE |
| Housing Index | FIXED |
| Weight (Kg) |
Cross-reference parts
- 96147592 ,
- 5802Q2 ,
- 96014184 ,
- 96155198 ,
- 96035033 ,
- 95667754 ,
- 5802L6 ,
- 5802J0 ,
- 5802E1 ,
- 95656487 ,
- 580288 ,
- 5802E4 ,
- 96035034 ,
- 5802ES ,
- 9613230280 ,
- 1319121080 ,
- 961323028 ,
- 71716554 ,
- 9613015980 ,
- 9615519880 ,
- 9619310280 ,
- 5802T6
