Description
Description
| Specifications | |
| Voltage | 12V |
| Kilowatt | 1.2kW |
| Number of Teeth | 9T |
| Pinion Diameter | 29mm |
| Rotation | CW |
| Pinion at Rest | 25mm |
| Flange Diameter | 76mm |
| Mount Hole Center to Center | 105mm |
| Mount Hole Diameter | M10- 10mm |
| Overall Length | 200mm |
| Oil Sealed | |
| Series | |
| Ground | NEGATIVE |
| Housing Index | FIXED |
| Weight (Kg) |
Cross-reference parts
- 12417610343 ,
- 12417610350 ,
- 12417526236 ,
- 12417521123 ,
- 12417521122 ,
- 12417521116
