| Specifications | |
| Voltage | 12V |
| Kilowatt | 1.2kW |
| Number of Teeth | 9T |
| Pinion Diameter | 29mm |
| Rotation | CW |
| Pinion at Rest | 32mm |
| Flange Diameter | 75mm |
| Mount Hole Center to Center | 115mm |
| Mount Hole Diameter | 11mm- 13mm |
| Overall Length | 227mm |
| Oil Sealed | |
| Series | |
| Ground | NEGATIVE |
| Housing Index | FIXED |
| Weight (Kg) |
Cross-reference parts
- 31200RAAA010M3 ,
- 06312RAA505 ,
- MHG016 ,
- 31200RAAA010 ,
- 31200RAAA01
