Description
Description
| Specifications | |
| Voltage | 12V |
| Kilowatt | 1.2kW |
| Number of Teeth | 8T |
| Pinion Diameter | 25mm |
| Rotation | CW |
| Pinion at Rest | 30mm |
| Flange Diameter | 70mm |
| Mount Hole Center to Center | 101mm |
| Mount Hole Diameter | M10 |
| Overall Length | 200mm |
| Oil Sealed | |
| Series | |
| Ground | NEGATIVE |
| Housing Index | FIXED |
| Weight (Kg) |
Cross-reference parts
- M0T36071 ,
- M2T46781ZE ,
- M002T46781ZE ,
- M000T36071 ,
- 3110063J00 ,
- 3110080G0 ,
- 3110080G00 ,
- 3110086G00
